Temperature range | –40° to +70°C / -40° to +160°F |
Case | ABS case, completely sealed in epoxy |
Weight | 50 g / 2oz. |
Size (H x W x D) | 3.8 x 7.0 x 3.1 cm / 1.5 x 2.75 x 1.3 in. |
Wire | 18 AWG, 15 cm / 6 in. |
Voltage configurations | 28 to 150 volts |
Consumption | 0.2 mA |
Maximum input | 150 volts |
Maximum load current | 0.5 Amps DC |
Typical set points | On: Custom Voltage, Off: any setpoint to a maximum of .95 times the on setpoint |
